Hi-target V200
Good things come in small packages
*Compatibility with third-party software
Higher Accuracy and Precision
Equipped with the High-Performance Patch Antenna, enhances the low elevation angle tracking capabilities and keeps it maintaining a high gain for higher elevation satellites while tracking low-elevation satellites.
More Stability
Hi-Target Hi-Fix enables continuous connectivity and quality results even if you lose the signal while using the RTK base station or VRS network under extreme circumstances.
Greater Flexibility
It can bring accurate and reliable results and boost efficient fieldwork with self-developed built-in IMU and core algorithm.
More Portability
Equipped with an ultra-light EPP material instrument case of a high anti-strong impact, shock and impact resistance and a centering rod that can be contracted to 1.25 m, making it durable and portable in the fieldwork
| GNSS Feature | Specification | |
| GNSS Signal | Channels | 800+ |
| GPS | L1 / L2 / L5 / L2C | |
| BDS | B1 / B2 / B3 / B1C / B2a | |
| GLONASS | L1 / L2 / L3 | |
| Galileo | E1 / E5 AltBOC / E5a / E5b / E6 | |
| SBAS | L1 / L5 | |
| QZSS | L1 / L2 / L5 / L6 | |
| IRNSS | L5 | |
| Communication | Communication | Bluetooth:4.2 / 2.1+EDR, 2.4GHz |
| Wi-Fi:frequency 2.4GHz, Supports 802.11 b / g / n | ||
| Internal UHF Radio | Transmitting power:0.5W / 1W / 2W adjustable | |
| Supports multi-communication protocols:HI-TARGET | ||
| TRIMTALK450S, TRIMMARK III, TRANSEOT, SATEL-3AS, etc. |
| Physica | Internal battery | Internal 7.4V / 6800mAh lithium-ion rechargeable battery. |
| RTK Rover (Network) for 12 hours. Static:up to 15 hours | ||
| External powe | Power consumption:4.2W Dimensions (W×H):132mm×67mm | |
| Charging:using standard smartphone chargers or external power banks. | ||
| Weight:≤0.8kg (includes battery) Data storage:8GB ROM internal storage | ||
| Control Panel | LED Lamp | Satellite, Signal, Power |
| Physical button | 1 | |
| Environment | Water / Dustproof | IP67 |
| Shock and vibration | Designed to survive a 2m natural fall onto concrete | |
| Humidity | 100%, condensing | |
| Operation temperature | -30ºC~+70ºC | |
| Storage temperature | -40ºC~+80ºC | |
| I / O Interface | 1 × USB port, Type C | |
| 1 × SMA antenna connector | ||
| Data Formats | Output rate | 1Hz-20Hz. |
| Static data format | GNS, Rinex | |
| Network model | VRS, FKP, MAC; supports NTRIP protocol | |
| CMR& RTCM | CMR, RTCM 2.x, RTCM 3.0, RTCM 3.2 | |
| Navigation outputs ASCII | NMEA-0183 |
Company Files
Nanjing Hanzhong mapping equipment Co., Ltd. is a company to provide professional surveying and mapping services for the country mapping units. The company set sales, repair, and services, it is in specialized in sales of surveying instruments in domestic and abroad.
Mainly sales of total station, auto/digital level, auto/electronic theodolite, GPS, GNSS RTK, receiver, laser distance meter, handheld GIS,UAV. etc. And some accessories for these surveying instruments. We can provide trimble, spectra, sanding, hi-target, south, kolida, chc, stone, unistrong, foif and other well-known brands at home and abroad.
Our Company′s employees graduated from engineering, surveying, and mapping professional institutions of higher learning, they have professional knowledge, so we are the high-quality sales and service team to provide you with excellent quality instrument service, customized, comprehensive, practical, and efficient measuring solutions .At the same time also provide intimate after-sales service
Our aim: Integrity, professionalism, service
Our goal: To do the best mapping equipment supply service providers
FAQ:
Service
1.Any inquiries will be replied within 12 hours.
2.All our products have one year warranty, And we sure the products will be free from maintenance within warranty period.
3.All products will have been strictly quality checked in factory before sending out.
Payment
We accept payment by TT,Paypal, West union.
If you'd like other payment method, Pls let us know before the order
Delivery / shippment :
1.Usually, we will send out the products within 3-5 working days after the payment confirmed
2.Before shipment, pls supply the following information to us :
Contact person or company name,Detail address,Telephone No,Zipcode
3.The buyer are responsible for the tax and/or duty charged by their country.
Return and warranty:
1.All products are inspected before shipment, if you are not satisfactory with the purchase,you can exchange the items in one week,and you must contact us within 24 hour of receipt of the products.
2.The shipping charges are not refundable and the customer should be responsible for all the charges of return and reshipping.
3.For our majority products (Auto level, Theodolite, Total Station) we are offing 1 year warranty;
4.For small issues like missing or damaged part, key board, please send us the photos, we will send the required part and related instructions to you for free;
5. For big issues in one year warranty like EDX board, main board issue. We could only ask you to send the instrument back to us. Normally we will have it fixed in 10 working days and send back to you. You and we shall take care of the corresponding shipping cost on each side. For big issues out of one year warranty, the customer should be responsible for all the cost.
